DC01,DC03,DC04 Cold Rolled Plate
- 500Tons stock/month of all kinds grades
- Rich stock,Fast Delivery
- Factory wholesale price
- Professional package and transportation ensure product quality
- 24 hours service online
Contact us:
+86 13383877691DC01 is standard is EN 10130.And cold-rolled steel plate C01, DC02, DC03 and DC04 represent different grades of cold-rolled steel, and their deep-drawing properties are different.
DC 01 Ordinary material, DC 02, DC 03, DC 04 Deep drawing material the later the deep drawing performance is better.
DCO1 is generally not used for stretching, only for simple bending.
DC02 can be used for shallow stretching, but generally only for bending.
DC03 is kind of a stretch plate.
DC04 last one is the best tensile performance, can be used for deep stretching.
Products Detail:
| Product Name | DC 01 ,DC03,DC04Carbon Steel Sheet | |||
| Length | 1m-6m or as required | |||
| Width | 50-3000mm or as required | |||
| Thickness | 0.3-3.5mm for Cold Rolled Plate | |||
| Standard | AISI, ASTM, DIN, JIS, GB, SUS, EN,etc | |||
| Technique | Cold Rolled, Hot Rolled | |||
| Surface Treatment | 1. Galvanized 2. PVC,Black and color painting 3. Transparent oil,anti-rust oil 4. According to clients requirement | |||
| Certification: | API, CE, RoHS, SNI, BIS, SASO, PVOC, SONCAP, SABS, si | |||
| Material | GB: Q195, Q215, Q235A, Q235B, Q235C, Q235D, Q255A, 255B, Q275, Q295A, Q295B, Q345B, Q345C, Q345D, Q345E, Q390A, Q390B, Q390C,Q390D, Q390E, Q420, Q420B, Q420C, Q420D, Q420E, Q460D, Q460E, Q500D, Q500E, Q550D, Q550E, Q620D, Q620E, Q690D, Q690E EN:S185,S235JR, S275JR, S355JR, S420NL, S460NL S500Q, S550Q, S620Q, S690Q,SS400,1020,1050,A3,45#,60# ASTM: Grade B, Grade C, Grade D, A36, Grade 36, Grade 40, Grade42, Grade 50, Grade 55, Grade 60, Grade 65, Grade 80 JIS: SPCC, SS330, SPHC, SS400, SPFC, SPHD, SPHE DIN: DC01, DC02, DC03, St12,St13, St14, St15 16Mo3,16MnL,16MnR ,16Mng,16MnDR |
|||
| price terms: | FOB,CRF,CIF,EXW all acceptable | |||
| Application | 1.Automobile, Bridges, Buildings. 2.Machinery, Pressure vessel industries. 3.Ship building, Engineering construction. 4.Mechanical manufacturing, Pavement slab, ect. | |||
| MOQ | 3 tons.We also can accept sample order. | |||
| Payment terms | 30% T/T deposit in advance+70% T/T upon B/L copy; L/C at sight can be accepted | |||
| Export packing | Waterproof paper, and steel strip packed. | |||
| Standard Export Seaworthy Package.Suit for all kinds of transport,or as required | ||||
| Capacity | 20000Tons/Month | |||
Mechanical properties of DC01 DC03 DC04:
| Grade(DIN) | Yield strength "MPa | The tensile strength MPa | Elongation after breaking "(L.=80mm, b=20mm)% not less than | r value "c | n value "c | |||
| Nominal thickness mm | ||||||||
| 70 | 0.70～<1.0 | 1.0～<1.6 | ≥1.6 | |||||
| DC01 | 130～260 | ≥270 | 28 | 30 | 32 | 34 | ||
| DC03 | 120～240 | ≥270 | 32 | 34 | 35 | 36 | ||
| DC04 | 120～210 | ≥270 | 36 | 38 | 39 | 40 | ≥1.5 | ≥0.18 |
| DC05 | 110～190 | ≥260 | 38 | 39 | 40 | 41 | ≥1.8 | ≥0.2 |
| DC06 | 100～180 | ≥250 | 39 | 40 | 41 | 42 | ≥2 | ≥0.22 |
Certifacte & Bill of Loading：
We have built solid business ship with most third party inspection organizations. The representatives are SGS, VELOX,BV, Intertek, TUV, PMI, BV,LR, GL, RINA, ABS, CCS, NK, DNV, KR, etc.
Some certificate of origin,we had CO, FORM E,and also if your country need, we will supply you.
Factory Machines:
In order to meet and exceed the expectations of users with excellent products and services, and in order to better become the benchmark of ecological civilization construction industry. Our company has the following high quality machinery to meet the needs. The picture below is only part of it. If you want to know more comprehensively and understand the strength of the company, please send email or leave a message online.
Company Culture:
Our company is a big family full of humanistic care.Except meeting of technicist,logistic,salesman before placing order,to confirm the billet,and when start testing quality and quantity, and when ship goods out.
And also had The party members’ meetings.Every month,we will have a big party to relax with our own family members,and colleagues.
